CIP System Residential Water Purification Systems 5000 L/H For Waste Water Treatment

CIP system+5000Liters Per Hour RO System Water Treatment Machine for Waste Water Treatment

1. Product Description

Reverse osmosis (RO) is a water purification process in which water is forced through a semi-permeable membrane that removes 90-99% of tap water impurities. The result is water that is free of minerals and other contaminants. Membrane type determines the amount of dissolved solids a unit is capable of removing.

RO system is key part for the water treatment system, which is widely used to make the pure water anddrinking water. RO membrane removes many types of large molecules and ions from solutions by applying pressure to the solution when it is on one side of a selective membrane. The result is that the solute such as iron, Virus, bacteria and solids is retained on the pressurized side of the membrane and the pure solvent is allowed to pass to the other side.

Design Scope: Depending on client’s water test report

1) Raw water test report:Underground well water

2) RO Purified water capacity:5000L/H @ 25Deg C

3) RO system recovery : 50%-75%

4) Desalination ratio: more than 97%

5) System working Voltage/Power: 380V 50HZ three phase

6) Feed water Capacity & Working pressure :12000L/H

7) Outlet Purified water standard: TDS<3000PPM ; TDS<100PPM for drinking standard

2. Product Parameter

KYRO-5000LPH RO Water Treatment System:

1. Capacity: 5000L/H

2. Rated power: 7.5KW/H

3. RO System Rack Size: 2000*900*1800MM

4. Desalting rate:>=97%

5. Water recovery rate: 50-75%

6. Voltage: 380V 50Hz 3phase

3. Component

There are several kinds of consumables you need to replace regularly. (5000LPH)

a. Quartz sand: replaced about every 15 months. 50kg/bag, 1300KG/set , 26bags total
b. Activated carbon: replaced about every 15 months. 25kg/bag , 375KG/set , 15bags total
c. PP Filter cartridge: replaced about every 1 month. 9pcs/set
d. Ro membrane: replaced about every 2 year. 5pcs/set

We suggest you buy 1- 2 years of PP filter cartridges together with machine. Because these PP filter cartridges need to replace every month.

4. Optional Components

►. Regulating wheels

►. PC Touch Screen

►. Two-stage RO system

►. PH adjustment

►. CIP cleaning system

►. Auto or manual control valve

►. U-PVC or stainless steel pipe

►. UV sterilizer/Ozone Generator

►. Dosing system(anti-scale)/Water Softener

►. PE or stainless steel raw/pure water tank

►. FRP or stainless steel pre-treatment tank

5. Product Processing

(Water softener,dosing system,ozone generator or UV can be added if you need it. It depends on the quality of raw water ) raw water→raw water tank→ raw water pump→sand filter+ carbon filter→ security filter→high pressure pump→ reverse osmosis system→ water supply points

If any interests & any questions just feel free to buzz me anytime^-^
